Welded Wire Fence Products
Welded wire mesh fencing systems manufactured from low-carbon steel wire or galvanized wire, welded at every intersection for maximum rigidity. Our fence products include V-beam curved panels, double-wire fencing (6+5+6mm or 8+6+8mm), 3D curved panels, and heavy-duty security fencing. Surface treatments include electro-galvanized, hot-dipped galvanized (ASTM A123), PVC coating, and powder coating. Panel widths range from 2.0m to 3.0m with heights from 1.2m to 3.0m. Ideal for residential, commercial, industrial, agricultural, and high-security applications.
Fence Mesh
Welded wire mesh fence panels are manufactured from high-tensile steel wire with electric resistance welding at every intersection for superior joint strength. Available in galvanized (≥60g/m² pre-gal
Specifications
- Panel Height: 0.6m, 0.9m, 1.2m, 1.5m, 1.8m, 2.0m, 2.2m, 2.4m
- Panel Width: 2.0m, 2.5m, 3.0m (standard), custom available
- Wire Diameter: 2.5mm, 3.0mm, 3.5mm, 4.0mm, 5.0mm, 6.0mm
- Mesh Opening: 50×50mm, 50×100mm, 50×200mm, 100×100mm, 100×200mm
- Coating: Electro-galvanized, hot-dip galvanized, Galfan, PVC-coated (green/black/white)
- Post Type: Round (48/60mm), Square (50/60mm), Peach-post, with post caps
- Post Fixing: Base plate (bolted), direct embedment (concrete), spigot
- Top Treatment: Flat top, pointed top, anti-climb (barbed/razor wire)
- Gate Options: Single leaf (1-3m), double leaf (3-6m), sliding gate
- Standard: BS 1722-14, ASTM F2408, AS 1725, EN 10244
- Lead Time: 10-15 days standard, 5-7 days express
Get Factory-Direct Pricing Today
Custom sizes, coatings, and quantities available. Fast FOB Tianjin shipping worldwide.
Quality Assurance
Every product undergoes rigorous testing and quality control before shipment. We test for tensile strength, zinc coating weight, dimensional accuracy, and weld integrity to ensure compliance with international standards.
Material Testing
Raw materials tested for tensile strength, elongation, and chemical composition before production
Process Control
In-line quality checks during wire drawing, weaving, welding, and coating processes
Final Inspection
100% visual inspection plus random sampling for dimensional and mechanical property testing
Third-Party Certification
SGS, BV, and other accredited labs available for independent verification upon request
Need a Quote for Your Project?
Factory-direct pricing. Custom specs. FOB Tianjin. Response within 24 hours.
Common Applications
- Highway and expressway guardrail fencing
- Industrial park and factory perimeter security
- Sports field and stadium enclosures
- Agricultural and livestock fencing
- Construction site temporary fencing
- Military and airport high-security zones
- Residential community boundaries and gardens
Ready to Order? Get Your Custom Quote
Specify dimensions, wire diameter, and coating grade. We deliver worldwide.
Frequently Asked Questions
What is the difference between double-wire and single-wire fencing?
Double-wire fencing (also called 2D/3D mesh) uses two horizontal wires (6mm or 8mm) welded to a vertical wire (5mm or 6mm), creating a stronger panel that resists cutting and climbing. Single-wire panels are lighter and more economical. Double-wire fencing is recommended for high-security applications, while single-wire is suitable for residential and agricultural use.
Should I choose galvanized or PVC-coated fencing?
Hot-dipped galvanized fencing (ASTM A123, 70+ microns) provides 20-30 years of rust protection in most environments. PVC coating over galvanized wire extends life to 30-50 years and offers better aesthetics with color options (green, black, white, grey). For coastal or humid tropical areas, PVC-coated is strongly recommended.
What panel dimensions are available?
Standard panels are 2500mm wide x 1030-3030mm high. Mesh openings include 50x200mm, 55x200mm, 50x100mm, 76.2x12.7mm, and 100x50mm. Custom dimensions are available for project-specific requirements. Posts come in round (60mm, 76mm) or square (60x60mm, 80x80mm) profiles with base plates for surface mounting or ground spikes for direct burial.
How is welded wire fence installed?
Installation steps: (1) Set posts in concrete footings at 2.5m intervals, (2) Allow concrete to cure 24-48 hours, (3) Attach panels to posts with security clips or bolts, (4) Install post caps and accessories. For temporary fencing, use concrete blocks or ground spikes. Detailed installation guides are provided with each order.
Do you provide complete fencing systems with posts and accessories?
Yes. We supply complete systems including panels, posts, post caps, clips/bolts, and gates. Powder-coated accessories match panel color. We also supply temporary fencing panels with concrete feet and clamps for construction sites.
What is the lead time and minimum order quantity?
Standard products ship in 10-15 days. Custom specifications require 15-25 days. MOQ is typically one 20ft container (approx. 500-800 panels depending on specification). We offer FOB Tianjin and CIF pricing to major ports worldwide. Contact us for a project-specific quote.
