Wire Mesh Products — Gabion, Fence & Rockfall Protection Solutions

Gabion Mesh

Gabion mesh boxes are heavy-duty wire mesh containers made of hexagonal double-twist woven mesh, PVC-coated or Galfan (Zn-5%Al) galvanized steel wire. Mesh openings range from 60×80mm to 100×120mm, wi

Specifications

• Wire Diameter: 2.0mm, 2.2mm, 2.4mm, 2.7mm, 3.0mm, 3.4mm, 3.9mm, 4.0mm
• Mesh Size: 60×80mm, 80×100mm, 80×120mm, 100×120mm
• Coating: Heavy galvanized (≥245g/m²), Galfan Zn-5%Al (≥275g/m²), PVC-coated (0.4-0.6mm)
• Tensile Strength: 380-550 N/mm² (per ASTM A975)
• Selvedge Type: Welded selvedge, knotted selvedge
• Standard Sizes: 2×1×1m, 3×1×1m, 4×1×1m, 2×1×0.5m (custom available)
• Diaphragms: 1m intervals, same mesh as body
• Packaging: Folded flat on pallets, 50-100 pcs/bundle, PE film wrapped
• Certification: ISO 9001, ASTM A975, EN 10223-3, BS 8002
• Lead Time: 15-25 days for standard specs, 7-10 days express available

Slope Protection Mesh

Slope protection mesh systems include active rockfall netting (high-tensile wire rope nets anchored to unstable slopes), passive drapery mesh (chain-link or double-twist mesh covering exposed rock fac

Specifications

• Mesh Type: Active netting (high-tensile), passive drapery, debris flow barriers
• Wire Rope: 12mm, 16mm, 18mm, 20mm, 22mm diameter, 6×19+FC or 6×36WS+FC construction
• Rope Strength: 1770 N/mm², 1960 N/mm²
• Mesh Opening: 50×50mm, 80×100mm, 100×120mm, 200×200mm (ring net)
• Wire Diameter: 2.0mm, 2.2mm, 2.7mm, 3.0mm, 4.0mm
• Coating: Hot-dip galvanized (≥245g/m²), Galfan Zn-5%Al (≥350g/m²)
• Anchor Bolts: 25mm, 28mm, 32mm diameter; 2-6m embedment depth
• Spike Plates: 300×300mm, galvanized steel, with bolt locking system
• Energy Class: 500kJ, 1000kJ, 1500kJ, 2000kJ, 3000kJ (per EAD 340059)
• Standard: ETAG 027, EN 1997, ONR 24810, EAD 340059-00-0106
• Design Life: 50+ years with Galfan coating, 30+ years galvanized

Fence Mesh

Welded wire mesh fence panels are manufactured from high-tensile steel wire with electric resistance welding at every intersection for superior joint strength. Available in galvanized (≥60g/m² pre-gal

Specifications

• Panel Height: 0.6m, 0.9m, 1.2m, 1.5m, 1.8m, 2.0m, 2.2m, 2.4m
• Panel Width: 2.0m, 2.5m, 3.0m (standard), custom available
• Wire Diameter: 2.5mm, 3.0mm, 3.5mm, 4.0mm, 5.0mm, 6.0mm
• Mesh Opening: 50×50mm, 50×100mm, 50×200mm, 100×100mm, 100×200mm
• Coating: Electro-galvanized, hot-dip galvanized, Galfan, PVC-coated (green/black/white)
• Post Type: Round (48/60mm), Square (50/60mm), Peach-post, with post caps
• Post Fixing: Base plate (bolted), direct embedment (concrete), spigot
• Top Treatment: Flat top, pointed top, anti-climb (barbed/razor wire)
• Gate Options: Single leaf (1-3m), double leaf (3-6m), sliding gate
• Standard: BS 1722-14, ASTM F2408, AS 1725, EN 10244
• Lead Time: 10-15 days standard, 5-7 days express

Razor Barbed Wire

High-security razor barbed wire (concertina coil) manufactured from hot-dip galvanized steel strip. BTO-22 and CBT-65 profiles available. Core wire 2.0-4.0mm, galvanizing 60-245g/m². ASTM F1910 / ISO

Stainless Steel Rope Mesh

Hand-woven stainless steel rope mesh (304/316L) for zoo enclosures, walk-through aviaries, balustrade infill and fall protection. Ferrule and inter-woven constructions, rope 1.0-4.0mm, aperture 25-150

Specifications

• Material: Stainless steel 304 / 316L (mill certificate with every coil)
• Rope diameter: 1.0 / 1.2 / 1.5 / 1.6 / 1.8 / 2.0 / 2.4 / 2.5 / 2.8 / 3.0 / 3.2 / 3.5 / 4.0 mm
• Rope construction: 7×7 and 7×19 stranded stainless cable
• Mesh aperture (60° diamond): 25×25 mm up to 150×150 mm, woven to order
• Mesh type: Ferrule (stainless / aluminium clips) or inter-woven
• Finish: Natural, black oxidized, PVC-coated rope
• Panel size: Custom woven to your drawing — any shape, no MOQ
• Hardware: Border cable, turnbuckles, shackles, lacing rope supplied with mesh
