YB/T 4190-2018 certified gabion mesh, manufactured in our ISO 9001 factory. Ships worldwide from Tianjin, China. MOQ: 100 pcs.
All products manufactured to YB/T 4190-2018 standard. Custom sizes available on request.
Our factory is certified to the highest international standards for quality management, environmental management, and occupational health & safety.
| Parameter | Specification | Standard |
|---|---|---|
| Wire Diameter | 2.2mm / 2.7mm / 3.0mm / 3.4mm | YB/T 4190-2018 |
| Mesh Opening | 50×50mm, 60×80mm, 80×100mm, 100×120mm | YB/T 4190-2018 |
| Wire Tensile Strength | 350 - 550 MPa | YB/T 4190-2018 |
| Galvanizing | ≥ 245 g/m² (Hot-dip galvanized) | GB/T 1839 |
| Coating Options | Hot-dip galvanized / Galfan (Zn-5%Al) / PVC coated | - |
| Product Types | Gabion Boxes, Reno Mattresses, Gabion Baskets, Sack Gabions | EN 10223-3 |
| Box Sizes (Standard) | 2×1×0.5m, 2×1×1m, 3×1×0.5m, 3×1×1m (custom sizes available) | - |
| MOQ | 100 pcs per size | - |
| Delivery Time | 15-25 days (depending on order volume) | - |
| Port of Loading | Tianjin, China | - |
Located in Shenzhou, Hebei Province — China's wire mesh manufacturing hub. Over 15 years of production experience.
