Does your welded wire fence comply with Australian Standard AS 2423?

Yes, Haobo Metal manufactures welded wire fence panels that comply with AS 2423 (Coated Steel Wire Fencing Products for Terrestrial and Aquatic Applications). We provide full compliance documentation including coating thickness certificates, weld strength test reports, and UV resistance testing. Pre-production samples can be sent to Australian laboratories for independent verification.

What is the minimum order quantity for custom welded wire fence?

Our minimum order quantity for custom welded wire fence panels is one 20-foot container (approximately 5,000-8,000 panels depending on specifications). For standard specifications, smaller trial orders of 500-1,000 panels can be accommodated at slightly higher unit costs. Contact us with your specifications for a detailed quotation.

How do you ensure consistent quality across large fence orders?

We maintain quality consistency through multiple layers: (1) Pre-production sample approval by the client, (2) Automated welding machines with real-time weld monitoring, (3) In-line QC stations at regular intervals, (4) Batch testing for coating thickness and tensile strength, (5) Third-party pre-shipment inspection (SGS/BV). Our first-pass quality rate for large orders consistently exceeds 99%.

Welded Wire Fence for Agricultural Security in Australia: 120,000 Linear Meters

July 8, 2026

yle="color:#fff;margin-top:0">Project Overview

Project Location	Queensland, Australia
Product	PVC-Coated Welded Wire Fence Panels + Posts
Quantity	120,000 linear meters / 6,000 panels
Wire Specification	4.0mm horizontal, 3.0mm vertical, 150×50mm mesh
Client	Australian agricultural supply distributor
Completion	2024 Q2

The Challenge

An Australian agricultural supply company required 120,000 linear meters of heavy-duty welded wire fencing for livestock enclosures and property boundary demarcation across multiple cattle stations in Queensland. The key requirements were:

Australian Standard AS 2423 compliance — a strict regulatory requirement for imported fencing products
UV-stabilized PVC coating — to withstand Queensland's intense sun exposure (UV index 11+ in summer)
Kangaroo/wild dog exclusion capability — requiring specific mesh sizing and panel heights
Competitive landed cost — the Australian distributor needed to remain price-competitive against local manufacturers
Consistent quality across all 6,000 panels — the end-user stations would reject panels with visible defects

Our Solution

Haobo Metal developed a custom welded wire fence specification optimized for Australian agricultural conditions:

Technical Specifications


Parameter	Specification	Standard
Panel Size	2,500×1,800mm (L×H)	AS 2423
Horizontal Wire	4.0mm, Zn-5%Al coating + Green PVC	AS 2423
Vertical Wire	3.0mm, Zn-5%Al coating + Green PVC	AS 2423
Mesh Pattern	150×50mm (tighter at bottom for small animal exclusion)	Custom design
PVC Coating	0.6mm thickness, UV-stabilized, RAL 6005 Green	AS 2423
Post Type	60×60mm square tube, 2.0mm wall, hot-dip galvanized + powder coat	AS 1397

Quality Assurance Program

For this high-volume order, we implemented a comprehensive QA program:

Pre-production sample approval: 20 panels sent to the client's Australian warehouse for inspection and AS 2423 compliance verification
In-line QC stations: Weld integrity check every 50 panels, mesh opening tolerance every 100 panels, PVC coating thickness every 200 panels
UV aging test: PVC samples subjected to 1,000-hour QUV accelerated weathering per ASTM G154 — color change ΔE < 3.0
Loading supervision: SGS inspector present for all container loading — verifying panel count, packaging integrity, and moisture protection

Logistics & Cost Optimization

To deliver 120,000 linear meters competitively, we optimized the logistics chain:

Custom packaging: Panels nested 50 per bundle, reducing container utilization from 65% to 92%
Shipping route: Tianjin → Brisbane direct service (18 days) — avoiding transshipment delays
Total containers: 12×40' HQ, shipped in 3 batches of 4 containers at 2-week intervals
Cost savings: Optimized packaging saved approximately $8,500 in freight costs vs. standard bundling

Results

120,000m

Linear Meters Delivered

99.7%

First-Pass Quality Rate

$8,500

Freight Cost Saved

The first 3 containers were sold out within 4 weeks of arrival in Australia. The distributor has since placed a follow-up order for an additional 80,000 linear meters and expanded the product range to include matching gates and accessories.
